| Key Highlights | CB500F | CB500X |
|---|---|---|
| Price | ₹ 5.24 Lakh | ₹ 6.34 Lakh |
| Displacement | 471 cc | 471.03 cc |
| Power | 46.85 bhp @ 8600 rpm | 46.93 bhp @ 8500 rpm |
| Mileage | 28.6 kmpl | 28.6 kmpl |
| Top Speed | 112 km/h | 185 km/h |
| Max Power Highest power the engine/motor can produce. | 46.85 bhp @ 8600 rpm | 46.93 bhp @ 8500 rpm |
| Max Torque The highest twisting force the engine generates, which affects acceleration and pulling power. | 43 Nm @ 6500 rpm | 43.2 Nm @ 6500 rpm |
| Battery Type | Not avaliable | 12V, 7.0Ah |
| Engine Type Design and working of the two-wheeler's engine. | Liquid-cooled, parallel twin | 4 Stroke, SI Engine (Parallel Twin) |
| Displacement Engine cylinder capacity measured in cc. | N/A | 471 |
| Engine Oil | 3 L | N/A |
| No Of Cylinders | N/A | 2 |
| Range The maximum distance an electric two-wheeler can travel on a full charge. | 483 Km | N/A |
| Stroke Stroke is the piston’s movement inside the engine cylinder. Longer strokes give more torque, shorter strokes give more speed and higher RPM. | 66 mm | N/A |
| Valve Per Cylinder Number of valves in each engine cylinder. | N/A | 4 |
| Top Speed | 112 Km/h | 185 Km/h |
| Tyre Size | Front :120/70-17 Rear :160/60-17 | Front : 110/80-19 M/C 59H, Rear : 160/60-17 M/C 69H |
| Wheel Size | Front :431.8 mm,Rear :431.8 mm | Front :482.6 mm,Rear :431.8 mm |
| Wheels Type | N/A | Alloy |
| Ignition The system that starts the engine, usually via a key, button, or smart start. | N/A | Computer-Controlled Digital Transistorized With Electronic Advance |
| Wheelbase The distance from the center of the front wheel to the center of the rear wheel, affecting stability, handling, and riding comfort. | 1410 mm | 1443 mm |
| Abs (Anti-locking Braking System) Prevents wheel locking during hard braking, improving control and safety. | Dual Channel | Dual Channel |
| Front Brake Diameter | 320 mm | 310 mm |
| Fuel Supply | Fuel Injection | PGM-FI |
| Body Type The overall design and shape of the bike (e.g., cruiser, sports, scooter). | Street Bike | Adventure Bike |
| Frame The main structure holding the bike together. | Steel diamond | Steel Tube Type |
| Adjustable Windshield A windshield that can be raised, lowered or tilted left/right to improve wind protection and rider comfort. | N/A | Yes |
| Ground Clearance Distance between the bike’s lowest part and the ground. | 145 mm | 181 mm |
| Height | 1060 mm | 1412 mm |
| Kerb Weight Bike’s weight with fuel and fluids. | 189 Kg | 199 Kg |
| Length | 2080 mm | 2156 mm |
| Saddle Height Distance from the ground to the seat. | 785 mm | 830 mm |
| Seat Height Distance from the ground to the seat. | N/A | 830 mm |
| Width | 790 mm | 828 mm |
| Display A screen that shows important riding information like speed, fuel, and trip details. | N/A | Yes |
| Fuel Gauge Indicates the current fuel level in the tank. | N/A | Yes |
| Instrument Console The main dashboard displaying speed, fuel, engine stats, and warnings. | Digital | N/A |
| Techometer | N/A | Digital |
| Clutch A device that connects and disconnects the engine from the wheels for smooth gear shifts. | Wet multiplate | Multiplate Wet Clutch |
| Head Light | LED | LED, DC |
| Low Fuel Indicator A warning light when fuel is low. | Yes | N/A |
| Battery Capacity Total energy the battery can store. | 12 V 7.4 Ah | 12V, 7.0 Ah |
| Suspension Front | Conventional telescopic front forks | Telescopic Suspension |
| Suspension Rear | Prolink mono with 5-stage preload adjuster, steel square pipe swingarm | Honda ProLINK monoshock |
| Seat Type The design of the seat that affects comfort and seating position. | Split | Single |
| Stepup Seat | Yes | N/A |
| Additional Features | Honda Intelligent Security System | Emergency Stop Signal, Honda Ignition Security System |
